Threaded intervention
Key Design Features:
1. Threaded Retention Design
Precision Threaded Locking System – Bearing caps secured by high-strength threaded collars for maximum retention force and vibration resistance
Adjustable Preload Control – Threaded design allows precise bearing preload adjustment for optimal performance
Visual Torque Verification – Thread position indicators enable quick installation confirmation without disassembly
Tool-Assisted Maintenance – Standard socket wrenches enable fast bearing replacement and torque verification
Superior Locking Security – Precision-machined threads with locking compounds prevent loosening under extreme vibration and shock loads
2. Integrated Spline Yoke Configuration
Precision Spline Engagement – Hardened splines (HRC 58-62) ensure zero-backlash torque transmission and smooth sliding action
Telescopic Length Adjustment – Internal spline design allows axial movement for driveline length compensation
High-Torque Spline Profile – Involute or straight splines optimized for maximum load capacity and even stress distribution
Corrosion-Resistant Surface – Phosphated or coated splines prevent rust and ensure smooth operation over extended service life
3. Superior Torque Transmission
Precision-ground cross journal with hardened bearing surfaces (HRC 58-62)
Needle roller bearings with high load capacity and low friction
Operating angles up to 25°-30° (single joint), 40°+ with double joint configuration
4. Industrial-Grade Durability
Cross, bearing caps and yoke body manufactured from 20CrMnTi or 20Cr alloy steel
Carburizing and hardening heat treatment for wear resistance
Sealed grease lubrication with multi-lip nitrile rubber seals
Corrosion-resistant coating options: black oxide, zinc plating, or phosphating
5. Versatile Configuration Options
Single Joint with Spline Yoke – For simple angular misalignment with length adjustment
Double Joint Assembly – For parallel offset or high-angle applications with telescopic capability
Fixed or Sliding Yoke Ends – Choose fixed flange or splined slip yoke configurations
Multiple Connection Interfaces – Flange, welded, or splined end options available
Why Choose Hangzhou Ocean Industry Co., Ltd.?
20+ Years Manufacturing Experience in automotive driveline components
Global Export Network – Serving customers in 50+ countries
Advanced Production Facilities – CNC machining, heat treatment, dynamic balancing
Reliable Lead Times – 15-30 days for standard products, 45-60 days for custom orders
Professional Technical Support – Engineering team with automotive industry expertise
Long-term Partnership Approach – Dedicated account management for strategic clients
Hangzhou Ocean Industry Co., Ltd. is professional manufacturer and most of our goods are exported to Europe since 2005. The Threaded intervention from Hangzhou Ocean Industry Co., Ltd. is a precision-engineered mechanical coupling designed to transmit torque between two shafts that are angularly misaligned. Featuring an internal threaded retention system, this universal joint offers secure bearing cap retention, easy maintenance access, and reliable performance across a wide range of industrial and automotive applications.
Crafted with high-grade alloy steel and precision machining, this universal joint ensures smooth power transmission, minimal backlash, and extended service life even under demanding operating conditions.
